T3 Driver
Part ID:
21300The T3 Post Driver is a small driver that delivers big time results! The T3 Driver will drive T-posts up to a 3" O.D. (outside diameter) pipe at a rate of up to six strikes per second. The top of the post is fully contained to prevent kick out and protected from damage by the strike plate. Use your tractor, skid-steer, mini-ex, loader, or backhoe to carry the weight of the driver.
We offer several mounting options, including an offset skid-steer quick attach which allows the operator to drive parallel to the fence line, a bolt-on/weld-on bracket that mounts to almost any flat surface, and a tilt bracket for up to 20° adjustments left or right. Use down pressure from the host vehicle to drive more posts in the ground faster.
The T3 Driver includes one bolt-on/weld-on bracket, hoses and flat face ISO couplers for simple plug and play operation. This is an ideal post driver for most farmers, ranchers, fencing contractors, and rental yards.
-
Post Dimensions (inches)
T-posts to 3" O.D. pipe
-
Impact Force
2,000 lbs. per stroke
-
Impact Energy
40 ft.-lbs. per stroke
-
Hammer Weight
10 lbs.
-
Strokes per Second
6
-
Mounts Table and Data
Mounts T3 Driver Skid-Steer Skid-Steer Offset Euro/Global John Deere 200-500 Series Overall Depth (inches) 12" 14" 18" 16" 15" Overall Width (inches) 11" 45.5" Extendable
50.5" - 86.5"45" 49" Overall Height (inches) 17" 19" 19" 21" 24" Weight 86 lb. 173 lb. 286 lb. 181 lbs. 193 lb. Hydraulic Requirements 1,500 - 3,000 PSI
& Up to 30 GPM** T3 Driver will operate at 6 strikes per second on vehicles with 15-30 GPM. It will function at fewer strikes per second below 15 GPM.
